HH-ZW20 色谱柱温箱

色谱柱恒温箱能够，稳定的控制色谱柱的工作温度，有效提高柱效，改善色谱峰分离度，保护横流泵并延长色谱柱的使用寿命，重现性，是液相色谱的重要配套装置。色谱柱温箱

色谱柱温箱
色谱柱温箱 详细信息：

仪器介绍

色谱柱恒温箱能够，稳定的控制色谱柱的工作温度，有效提高柱效，改善色谱峰分离度，保护横流泵并延长色谱柱的使用寿命，重现性，是液相色谱的重要配套装置。

主要特点
1.选用温控器，PID调节，数字显示。
2.加热元件，运行安全。
3.触摸式调节按键，温度调节方便自如。
4.独特的加热腔室设计，可放置多种规格的色谱柱。
5.可安装进样阀，以提高恒温精度。
6.预留多个进出液路管口，减少液路管长度。
7.卧式柱温箱，结构简洁，操作方便。

技术参数
温控范围：室温+5℃～100℃
控温精度：±0.3℃
加热功率：220W
电 源：220V±22V/50Hz±1Hz
色谱柱长度：250mm
色谱柱容纳数量：2支
恒温腔内尺寸：415Lx45Wx40H (mm)
外形尺寸：450Lx75Wx150H (mm)
重 量：2.5Kg

色谱柱温箱 图片：



Instrument introduction
Column thermostats provide accurate and stable control of the column's operating temperature, improve column efficiency, improve chromatographic peak resolution, protect cross-flow pumps, extend column life and ensure reproducibility, and are important for high performance liquid chromatography Supporting device.
main feature
1. Selection of high-quality thermostat, PID regulator, digital display. In this case,
2. Advanced heating elements, safe and reliable operation. In this case,
3. Touch-type adjustment button, the temperature adjustment convenient.
4. Unique heating chamber design, can be placed a variety of specifications of the column.
5. Can be installed injection valve, in order to improve the accuracy of constant temperature.
6. Reserve a number of inlet and outlet liquid pipe mouth, reducing the length of liquid pipe.
7. Horizontal column oven, simple structure, easy to operate.
Technical Parameters
Temperature range: room temperature +5 ℃ ~ 100 ℃
Temperature control accuracy: ± 0.3 ℃
Heating power: 220W
Power supply: 220V ± 22V / 50Hz ± 1Hz
Column length: 250 mm
Number of columns: 2
Constant temperature chamber size: 415Lx45Wx40H (mm)
Overall dimensions: 450Lx75Wx150H (mm)
Weight: 2.5Kg
