HHT-500除烃净化器
简单介绍
HHT-500除烃净化器的详细介绍
HHT-500除烃净化器
HHT-500除烃净化器 详细信息:
除烃净化器是一种净化空气源的装置,通过对压缩空气中的总碳氢化合物进行催化裂解产生低于0.1ppm碳氢化合物的零级空气。
1.仪器稳定时间: <15分钟
2.使用环境温度: -20 -40℃
3.使用环境湿度: <85%
4.工作电源:220V/50Hz
5.输出流量:可按要求定制(详见表格)
输入气体:烃类浓度(如甲烷)<100ppm;
CO2含量 ≤1%;
输出流量:见表(可按要求定制);
压力: 0~0.4Mpa;
气体:烃类浓度(如甲烷)≤0.05ppm;
残留CO2含量:≤0.01ppm;
颗粒物含量≤0.01um;
输入气体流量的范围为0~50000ml/min(视机体型号而定)
HHT-500除烃净化器 详细信息:
零级空气发生器(除烃类净化器) |
||||
型 号 |
纯 度 |
压力MPa |
输出流量 Nml/min |
体积(mm3)长×宽×高 |
HHT-500 |
除烃≤0.01PPM |
0-0.4 |
0-500 |
180×300×320 |
HHT-1L |
0-1000 |
180×300×320 |
||
HHT-2L |
0-2000 |
180×300×320 |
||
HHT-5L |
0-5000 |
180×300×320 |
||
CT-10L型 |
0-10000 |
280×460×430 |
||
CT-20L型 |
0-20000 |
280×460×430 |
||
CT-30L型 |
0-30000 |
280×460×430 |
A hydrocarbon removal unit is a source of clean air that generates zero-order air with less than 0.1 ppm of hydrocarbons by catalytic cracking of the total hydrocarbons in the compressed air.
1. Instrument stabilization time: <15 minutes
2. Use of the ambient temperature: -20 -40 ℃
3. Operating humidity: <85%
4. Working power: 220V / 50Hz
5. Output flow: can be customized (see table)
Input gas: Hydrocarbon co
CO2 co
Output flow: see table (can be customized);
Pressure: 0 ~ 0.4Mpa;
Gas: hydrocarbon co
Residual CO2 content: ≤ 0.01ppm;
Particle co
The input gas flow range is 0 ~ 50000ml / min (depending on the body model)
Zero-class air generators (except hydrocarbon cleaners)
Model number
Purity
Pressure MPa
Output flow Nml / min
Volume (mm3) length × width × height
HHT-500
In addition to hydrocarbon ≤ 0.01PPM
0-0.4
0-500
180 × 300 × 320
HHT-1L
0-1000
180 × 300 × 320
HHT-2L
0-2000
180 × 300 × 320
HHT-5L
0-5000
180 × 300 × 320
CT-10L type
0-10000
280 × 460 × 430
CT-20L type
0-20000
280 × 460 × 430
CT-30L type
0-30000
280 × 460 × 430
