Bruker 456GC 布鲁克气相色谱仪用甲烷转化炉

布鲁克气相色谱仪用甲烷转化炉，液化石油气，二甲醚，甲缩醛，乙缩醛，乙醇，室内空气，焦炉煤气，炼厂气，天然气，变压器油，多氯联苯，植物油，6号溶剂残留，裂解进样器，三甲胺

布鲁克气相色谱仪用甲烷转化炉
布鲁克气相色谱仪用甲烷转化炉 详细信息：

用1台气相色谱仪、两气路通道,2个氢火焰检定器、1个甲烷转化炉一次进样同时测定出聚合级丙烯中微量烃类杂质及微量CO、CO2的全分析方法.采用Al2O3毛细管色谱柱、Resin填充柱、以氦气作载气,分别测定和计算各自的定量校正因子,经过多次实验,找出了该方法的色谱操作条件,建立了一种简单、准确、快速测定聚合级丙烯中的微量杂质分析方法.该方法检测限可达到1×10-6,相对误差小于5%,相对标准偏差小于10%,分析速度快(30 min可完成一次全分析)、稳定性好、效率高、结果准确.

微量CO,甲烷及CO2需要加装甲烷转化炉，需要改变仪器原来的构造 ，费时费力，且较为转化炉体积较大，安装十分复杂，电路，气路，色谱柱，检测器，等都需要连接，仪器使用者根本无法单独操作，成本高昂。

滕州市浩瀚色谱仪器技术服务有限公司，研发出微型甲烷转化炉和布鲁克气相色谱仪Bruker 456GC浑然一体，美观大方，安装简单，调试方便，浩瀚色谱提供详细的分析方案，客户根据方案即可完成安装及调试，一氧化碳，二氧化碳分离好，出峰快，结果准确。

布鲁克气相色谱仪用甲烷转化炉  测试谱图：



Methane Reformer for Bruker Gas Chromatograph
Methane Reformer for Bruker Gas Chromatograph Details:

Using 1 gas chromatograph, two gas passages, 2 hydrogen flame detectors, and 1 methane reformer for one sample injection, the whole analysis method of trace hydrocarbon impurities and trace CO and CO2 in polymer grade propylene are simultaneously determined. Using Al2O3 Capillary chromatographic column, Resin packed column, and helium as the carrier gas were used to measure and calculate their respective quantitative correction factors. After many experiments, the best chromatographic operating conditions for this method were found, and a simple, accurate, An analytical method for the rapid determination of trace impurities in polymer-grade propylene. The detection limit of this method can reach 1×10-6, the relative error is less than 5%, the relative standard deviation is less than 10%, and the analysis speed is fast (a full analysis can be completed in 30 minutes), Good stability, high efficiency, accurate and reliable results.

Micro CO, methane and CO2 need to install a methane reformer, the original structure of the instrument needs to be changed, time-consuming and laborious, and the reformer is larger in size, the installation is very complicated, the circuit, gas circuit, chromatographic column, detector, etc. need to be connected , The user of the instrument cannot operate alone at all, and the cost is high.

Tengzhou Haohan Chromatography Instrument Technology Service Co., Ltd. has developed a miniature methane reformer and Bruker 456GC gas chromatograph, which are integrated, beautiful, simple to install, and convenient to debug. Haohan Chromatography provides detailed analysis solutions, and customers can complete the installation according to the plan. And debugging, the separation of carbon monoxide and carbon dioxide is good, the peak is fast, the result is accurate and reliable.

Methane reformer for Bruker gas chromatograph test spectrum:
