5Å 分子筛气相色谱填料

5Å​分子筛气相色谱填料，液化石油气，二甲醚，甲缩醛，乙缩醛，乙醇，室内空气，焦炉煤气，炼厂气，天然气，变压器油，多氯联苯，植物油，6号溶剂残留，裂解进样器，三甲胺，二甲醚，乙酸

5Å分子筛气相色谱填料
5Å分子筛气相色谱填料 详细信息：

粒度：100-120目
规格：25g/瓶
型号：5Å
应用：气体分析H2/O2N2/CO/CH4分离

为配合执行GBZ/T 205—2007《密闭空间作业职业危害防护规范》,滕州市浩瀚色谱仪器技术服务有限公司，提出空气中氧气的气相色谱直接测定方法。采用5Å分子筛做为气相色谱固定相,完成空气中氧气与氮气的分离任务,使用TCD测定。结果显示,该方法空气中氧气的检出限为1.8%,进样量为1ml气体。方法重现性可以满足要求,相对标准偏差：5%含量为2.8%,10%含量为2.0%,30%含量为3.5%。样品在室温状态可以保存7 d。提示,本方法适用于工作场所空气中氧气含量检测工作。

5Å分子筛气相色谱填料 测试谱图：




5Å molecular sieve chromatography packing
5Å molecular sieve chromatography packing Details:

Particle size: 100-120 mesh
Specification: 25g/bottle
Model: 5Å

In order to cooperate with the implementation of GBZ/T 205-2007 "Occupational Hazard Protection Code for Confined Space Work", Tengzhou Haohan Chromatography Instrument Technology Service Co., Ltd. proposed a direct gas chromatography method for the determination of oxygen in the air. Use 5Å molecular sieve as the gas chromatography stationary phase to complete the separation of oxygen and nitrogen in the air, and use TCD to determine. The results show that the detection limit of oxygen in the air by this method is 1.8%, and the injection volume is 1ml gas. The reproducibility of the method can meet the requirements. The relative standard deviation: 5% content is 2.8%, 10% content is 2.0%, and 30% content is 3.5%. The sample can be stored for 7 days at room temperature. Tips, this method is suitable for the detection of oxygen content in the air in the workplace.

5Å molecular sieve chromatography packing test spectrum:
