HH-5毛细管柱 工业用顺丁烯二酸酐纯度测定
如果你感兴趣的话，可以电话：0632-5667636
产品名称：HH-5毛细管柱 工业用顺丁烯二酸酐纯度测定
产品型号：HH-5毛细管柱
产品厂商：浩瀚色谱（山东）应用技术开发有限公司
简单介绍
工业用顺丁烯二酸酐纯度测定,，液化石油气，二甲醚，甲缩醛，乙缩醛，乙醇，室内空气，焦炉煤气，炼厂气，天然气，变压器油，多氯联苯，植物油，6号溶剂残留，裂解进样器，增塑剂
HH-5毛细管柱 工业用顺丁烯二酸酐纯度测定的详细介绍
工业用顺丁烯二酸酐纯度测定
工业用顺丁烯二酸酐纯度测定 详细信息：
GB/T 3676-2020 工业用顺丁烯二酸酐
工业用顺丁烯二酸酐纯度测定 详细信息：
色谱柱HH-5
５％苯基甲基聚硅氧烷毛细管柱
规格
３０ｍ×０．３２ｍｍ×０．２５μｍ
柱温
初始５０ ℃，保持２ｍｉｎ；升温速度６０ ℃／ｍｉｎ，升温１１０ ℃，保持
０．５ｍｉｎ；升温速度２０℃／ｍｉｎ，升温２１０℃，升温速度３０℃／ｍｉｎ，升
温２４０℃
汽化室温度／℃
２８０
检测器温度／℃
３００
柱载气（Ｈ２）流量／（ｍＬ／ｍｉｎ）
４
氢气流量／（ｍＬ／ｍｉｎ）
３０
空气流量／（ｍＬ／ｍｉｎ）
３００
尾吹气（Ｎ２）流量／（ｍＬ／ｍｉｎ）
２８
进样量／μＬ
０．５
分流比
１００∶１
GB/T 3676-2020 工业用顺丁烯二酸酐
本标准规定了工业用顺丁烯二酸酐的要求、试验方法、检验规则以及标志、包装、运输和贮存。
本标准适用于以苯或正丁烷为原料经催化氧化制得的顺丁烯二顺酐。
工业用顺丁烯二酸酐纯度测定 测试谱图：
Purity determination of maleic anhydride for industrial use
Determination of purity of maleic anhydride for industrial use Details:
Column HH-5
5% phenyl-methyl polysiloxane capillary column
specification
30m×0.32mm×0.25μm
Column temperature
Initially 50 ℃, keep 2min; heating rate 60 ℃/min, heating up to 110 ℃, keep
0.5min; heating rate 20℃/min, heating up to 210℃, heating speed 30℃/min, liter
Temperature to 240℃
Vaporization chamber temperature/℃
280
Detector temperature/℃
300
Column carrier gas (H2) flow rate/(mL/min)
4
Hydrogen flow rate/(mL/min)
30
Air flow/(mL/min)
300
Makeup gas (N2) flow rate/(mL/min)
28
Injection volume/μL
0.5
Split ratio
100:1
GB/T 3676-2020 Maleic anhydride for industrial use
This standard specifies the requirements, test methods, inspection rules, marking, packaging, transportation and storage of maleic anhydride for industrial use.
This standard applies to maleic anhydride prepared by catalytic oxidation using benzene or n-butane as raw materials.
Determination of purity of maleic anhydride for industrial use Test spectrum:
工业用顺丁烯二酸酐纯度测定 测试谱图：
Purity determination of maleic anhydride for industrial use
Determination of purity of maleic anhydride for industrial use Details:
Column HH-5
5% phenyl-methyl polysiloxane capillary column
specification
30m×0.32mm×0.25μm
Column temperature
Initially 50 ℃, keep 2min; heating rate 60 ℃/min, heating up to 110 ℃, keep
0.5min; heating rate 20℃/min, heating up to 210℃, heating speed 30℃/min, liter
Temperature to 240℃
Vaporization chamber temperature/℃
280
Detector temperature/℃
300
Column carrier gas (H2) flow rate/(mL/min)
4
Hydrogen flow rate/(mL/min)
30
Air flow/(mL/min)
300
Makeup gas (N2) flow rate/(mL/min)
28
Injection volume/μL
0.5
Split ratio
100:1
GB/T 3676-2020 Maleic anhydride for industrial use
This standard specifies the requirements, test methods, inspection rules, marking, packaging, transportation and storage of maleic anhydride for industrial use.
This standard applies to maleic anhydride prepared by catalytic oxidation using benzene or n-butane as raw materials.
Determination of purity of maleic anhydride for industrial use Test spectrum:
