HH-Transformer oil 变压器油专用填充柱

名称：变压器油专用柱

规格：5m*3mm，6m*3mm

型号·：HH-Transformer oil

应用：变压器油溶解气七组分单柱测定

现有变压器油色谱柱一般常用不锈钢管或管内填充碳分子筛固定相构成，管子成U形或螺旋形。一般柱管内径为2毫米，柱管长度一般为1米3米。但存在色谱柱不耐油、易被污染，从而使用寿命短等问题。随着社会的发展，电力系统的扩大建设，需要检测的变压器越来越多，现有传统的变压器油色谱柱已经不能满足要求。

浩瀚色谱（山东）应用技术开发有限公司，，研发出一根填充柱测定变压器油溶解气中H2,CO,CH4,CO2,C2H4,C2H4,C2H4七组分的含量，柱效高，分离好，结果满意。


变压器油专用填充柱 测试谱图：




Packing column for transformer oil
Special filling column for transformer oil Details:

Name: Special column for transformer oil

Specification: 5m*3mm, 6m*3mm

Model·: HH-Transformer oil

Application: single-column determination of seven components of dissolved gas in transformer oil

The existing transformer oil chromatographic column is generally composed of a stainless steel tube or a tube filled with a carbon molecular sieve stationary phase, and the tube is U-shaped or spiral-shaped. Generally, the inner diameter of the column tube is 2 mm , and the length of the column tube is generally 1 meter to 3 meters. However, the chromatographic column is not resistant to oil, easy to be contaminated, and has a short service life. With the development of society and the expansion and construction of power systems, more and more transformers need to be tested. The existing traditional transformer oil chromatography columns can no longer meet the requirements.

Haohan Chromatography (Shandong) Applied Technology Development Co., Ltd. keeps pace with the times and has developed a packed column to determine the content of the seven components of H2, CO, CH4, CO2, C2H4, C2H4, and C2H4 in the dissolved gas of transformer oil, with high column efficiency, The separation is good, and the result is satisfactory.


Special packed column for transformer oil test spectrum:
