HH-624毛细管柱测定 HG/T5626-2019工业用乙酸甲酯

HG/T5626-2019工业用乙酸甲酯，液化石油气，二甲醚，甲缩醛，乙缩醛，乙醇，室内空气，焦炉煤气，变压器油，多氯联苯，植物油，增塑剂，塑化剂，过氧化物，乙酸乙酯，口罩

HG/T5626-2019工业用乙酸甲酯
HG/T5626-2019工业用乙酸甲酯 详细信息：

名称：毛细管柱
固定相：6 %腈丙基苯基 94 %二甲基聚硅氧烷，
规格：60m*0.32mm*1.8um
型号：HH-624

应用：HG/T 5626-2019 工业用乙酸甲酯

范围
本标准规定了工业用乙酸甲酯的要求、试验方法、检验规则及标志、包装、运输和贮存。
本标准适用于聚乙烯醇行业副产的工业用乙酸甲酯以及以醋酸与甲醇合成工艺生产的工业用乙酸甲酯。
分子式: CH₃COOCH₃
结构式:

相对分子质量: 74.08(按2016年相对原子质量)

分型
工业用乙酸甲酯分为: Ⅰ型和Ⅱ型，Ⅰ型包括聚乙烯醇行业副产的乙酸甲酯，醋酸与甲醇合成工艺生产的乙酸甲酯，Ⅰ型的纯度≥99.00%；Ⅱ型为聚乙烯醇行业副产的纯度≥76.0%的工业用乙酸甲酯。

要求
外观
无色透明液体，无机械杂质。
技术指标
工业用乙酸甲酯质量应符合表1所示的技术指标

HG/T5626-2019工业用乙酸甲酯 测试谱图：




HG/T5626-2019 Methyl acetate for industrial use
HG/T5626-2019 Industrial Methyl Acetate Details:

Name: capillary column
Stationary phase: 6% nitrile propylphenyl 94% dimethylpolysiloxane,
Specifications: 60m*0.32mm*1.8um
Model: HH-62

Application: HG/T 5626-2019 Industrial Methyl Acetate



scope
This standard specifies the requirements, test methods, inspection rules and marking, packaging, transportation and storage of methyl acetate for industrial use.
This standard applies to the industrial methyl acetate produced by the polyvinyl alcohol industry and the industrial methyl acetate produced by the synthesis process of acetic acid and methanol.
Molecular formula: CH3COOCH3
Structural formula:

Relative molecular mass: 74.08 (according to 2016 relative atomic mass)

Type
Industrial methyl acetate is divided into: type I and type II. Type I includes methyl acetate by-product in the polyvinyl alcohol industry, and methyl acetate produced by the synthesis process of acetic acid and methanol. The purity of type I is ≥99.00%; type II is The by-product of the polyvinyl alcohol industry is industrial methyl acetate with a purity of ≥76.0%.

Require
Exterior
Colorless transparent liquid, no mechanical impurities.
Technical indicators
The quality of industrial methyl acetate should meet the technical indicators shown in Table 1

HG/T5626-2019 Industrial methyl acetate Test spectrum:
