30m*0.53mm PLOT-TDX-01碳分子筛石英毛细管柱

名称：毛细管柱

固定相：碳分子筛

规格：30m*0.53mm

型号：PLOT-TDX-01

浩瀚色谱（山东）应用技术开发有限公司选用碳分子筛作吸附剂 ,用液相沉淀法涂渍出PLOT碳分子筛石英毛细管色谱柱 ,并对其色谱性能进行了考察。结果表明 ,该色谱柱具有良好的分离特性 ,1次进样可分离出O2、N2、CO、CO2、CH4、C2H2、C2H4、C2H6 等组分;适用于炼厂气、烟道气、水煤气及变压器油溶解气等的分析。

PLOT-TDX-01碳分子筛石英毛细管柱  测试谱图：



PLOT-TDX-01 High Efficiency Carbon Molecular Sieve Quartz Capillary Column
PLOT-TDX-01 High Efficiency Carbon Molecular Sieve Quartz Capillary Column Details:

Name: capillary column

Stationary Phase: Carbon Molecular Sieve

Specifications: 30m*0.53mm

Model: PLOT-TDX-01

Haohan Chromatography (Shandong) Application Technology Development Co., Ltd. selected carbon molecular sieve as adsorbent, and coated high-efficiency PLOT carbon molecular sieve quartz capillary column by liquid precipitation method, and its chromatographic performance was investigated. The results show that the chromatographic column has good separation characteristics, and can separate O2, N2, CO, CO2, CH4, C2H2, C2H4, C2H6 and other components in one injection; it is suitable for refinery gas, flue gas, water gas and other components. Analysis of transformer oil dissolved gas, etc.

PLOT-TDX-01 High Efficiency Carbon Molecular Sieve Quartz Capillary Column Test Spectrum:
